The frame fence gate is a universal access solution built for various fence systems. It consists of a steel pipe frame and a steel wire mesh panel, assembled through welding and fabrication processes. This product delivers both boundary protection and controlled passage functions, and can be paired with multiple fence types to fit different site layouts. It is widely used across commercial, industrial and public spaces, supporting routine personnel and vehicle access while maintaining site perimeter security.
The gate frame is made of rectangular or circular steel pipes. All pipe joints are welded to form an integrated structure, which distributes external force across the entire frame body. The frame shape follows standard fence opening dimensions, and can be adjusted to match existing fence line layouts.
Three panel types are available to align with different fence styles and protection requirements:
Welded wire mesh
Chain link mesh
Expanded metal mesh Each panel type is fixed to the inner edge of the steel pipe frame, with uniform connection points along the full frame perimeter.
Three anti-corrosion surface treatments are available to adapt to different outdoor exposure conditions:
Hot-dip galvanizing
Plastic coating
Spray coating Each treatment forms a continuous protective layer over all exposed metal surfaces.
The welded steel pipe frame provides structural support for daily use and regular external impact. The integrated welding design reduces loose connection points, and the frame maintains dimensional stability under rated use conditions. Panel mesh is fixed at multiple points to prevent displacement under external force.
The surface protective layer covers all exposed metal surfaces, creating a barrier against moisture, salt spray and acid-alkaline exposure. Different treatment options correspond to different outdoor service durations, supporting long-term use in open-air environments.
The gate is fitted with hinges and locking hardware, supporting smooth opening and closing with low risk of jamming. Manual operation is standard, and automated operation configurations are available on request. All exposed edges and corners undergo smoothing processing, with no protruding burrs on contact surfaces. The locking mechanism restricts unauthorised access when the gate is closed.
This gate type adapts to a wide range of site protection and access needs. Common application areas include residential communities, factory perimeters, community compounds, public parks, agricultural farms and highway boundary zones. It can be matched with corresponding fence systems to provide consistent boundary protection and controlled access points.
Parameter Category | Available Options / Range |
|---|---|
Frame pipe form | Rectangular steel pipe, circular steel pipe |
Panel type | Welded wire mesh, chain link mesh, expanded metal mesh |
Surface treatment | Hot-dip galvanizing, plastic coating, spray coating |
Dimension range | Width and height customizable to fit fence opening size |
Adjustable details | Frame thickness, wire diameter, mesh opening size |
Color option | Multiple color options for surface coating |
All core dimensions and material specifications can be adjusted according to project requirements. Customers may specify gate width, height, frame thickness, wire diameter, mesh size and surface treatment color, to match existing fence systems and site conditions.
The gate is prefabricated in factory conditions before delivery, supporting on-site assembly and connection with matching fence systems. Installation requires basic fixing hardware, with no complex on-site fabrication work. Routine maintenance consists of regular surface cleaning and periodic hardware inspection.
Yes. The gate supports three panel types and adjustable dimensions, and can be paired with most common fence systems by matching panel style and overall dimensions.
Hot-dip galvanizing provides base corrosion resistance for coastal areas. For higher salt spray exposure, plastic coating over a galvanized base can be selected to extend service life in such environments.
Yes. Each gate is supplied with matching hinges and locking components as standard. Automated opening and closing hardware can be added per customer request.
We produce frame fence gates with standardized welding and surface treatment processes, and supply products to commercial and enterprise customers across multiple regions. We support bulk orders, custom specification requests and project-based procurement. Delivery arrangement, on-site installation guidance and after-sales consultation are available for all orders. Customers may contact our team to confirm specifications, request quotations or discuss project-specific requirements.
