The 6×36 general purpose steel wire rope is a multi-strand wire rope product, evolved from the 6×19 wire rope structure. It consists of 6 separate strands, with 36 individual steel wires in each strand. The structure features a denser strand composition compared to 6×19 wire rope, and balances load capacity with flexibility for medium and heavy duty use cases. It is used across lifting, traction, hoisting and transportation operations in industrial settings.
Each rope contains 6 helically twisted strands. Every strand incorporates 36 steel wires, arranged in a layered structure. The increased wire count per strand creates a more compact cross-section compared to 6×19 wire rope, with a larger number of contact points between individual wires.
The rope is manufactured from high-carbon steel wire. Production includes precision stranding and heat treatment processes, with controlled twisting pitch across all strands. The production process follows general industrial steel wire rope standards, with consistent strand tightness across the full rope length.
Two base material configurations are available: galvanized and non-galvanized. Galvanized versions include a zinc coating over the steel wire surface for additional corrosion resistance. Length can be cut to customer-specified dimensions.
The multi-wire strand structure distributes load across a larger number of individual wires. The rope has a defined tensile strength rating, with consistent breaking force performance across the full length. It is suited for medium and heavy lifting and traction operations.
With 36 wires per strand, the rope has a higher degree of flexibility compared to 6×19 wire rope. It can bend around pulleys and drums with smaller diameters, and supports use in spaces with limited operating room. The flexible structure also supports repeated winding and unwinding operations.
The closely twisted wire arrangement creates a smooth outer rope surface. The multi-wire structure distributes contact stress across more wires during bending and contact operations. The rope maintains consistent performance through repeated cyclic use under rated load conditions.
This wire rope type serves general purpose use across multiple industrial sectors. Common applications include general lifting work, hoisting operations, equipment traction, material transportation, construction site operations, auxiliary mining work and marine operation tasks. It fits scenarios that require both load capacity and bending flexibility.
Parameter Category | Specification / Range |
|---|---|
Structure | 6 strands, 36 wires per strand |
Base material | High-carbon steel wire |
Diameter range | 6mm - 50mm |
Length | Customizable per customer requirement |
Surface option | Galvanized, non-galvanized |
Application type | Medium and heavy general purpose use |
For scenarios with frequent bending and pulley use, the 6×36 structure is preferred over 6×19 wire rope due to higher flexibility. For outdoor or humid environments, galvanized configuration is recommended. Diameter selection should be based on actual working load and equipment specifications.
Routine inspection should check for broken wires, strand loosening and surface corrosion. Regular lubrication reduces friction between internal wires and extends service life. The rope should be stored in dry, covered areas when not in use, to avoid long-term exposure to moisture.
The 6×36 structure contains more wires per strand than the 6×19 type. This results in a more compact structure, better flexibility and more uniform force distribution, while the 6×19 structure has fewer wires and stiffer performance.
Yes. Length can be specified according to customer application requirements, with cut ends processed to prevent strand loosening.
Galvanized coating provides corrosion protection for general outdoor exposure. For highly corrosive environments such as coastal or chemical sites, additional protective measures may be required.
We manufacture 6×36 general purpose steel wire rope with controlled production processes and dimensional inspection. We supply to commercial and industrial customers for project and routine procurement needs. Bulk orders, custom length cutting and technical consultation services are available. Our team provides delivery coordination and usage guidance to support commercial procurement workflows. Customers may reach out to confirm specifications and request pricing details.
